l FTTX Systems
l LAN, WAN and Metro Networks
l Analog/Digital Passive Optical Networks
l CATV Networks
l Other applications in fiber optic systems
| Availability: | |
|---|---|
Low insertion loss,Low PDL (Polarization Dependent Loss)
Excellent Temperature stability
Compact Design
Environment protection (ROHS Compliance)
Polarization Insensitive
Various connector type
Specifications
| |
Wavelength (nm) | SMF:1310/1550 ; MMF:850/1300 |
Repetitiveness (dB) | ≤0.1 |
Attenuation range (dB) | 0-15 |
Attenuation tolerance (dB) | 0-5:±0.5 5-15:±10% |
Interchangeability (dB) | ≤0.2 |
Plug times | 1000times ≤0.2 |
MAX Optical Power(mw) | ≤200 |
Operating Temperature(℃) | -40~+85 |
Packing
| |
Simplex | 2000pcs/carton |
Weight | 8.5kg |
Carton Dimension | 470x310x210mm |
