Fiber Optic Attenuator


Product Name: Air-blowing Micro Cable
Fiber Type: Singlemode,Multimode,om1,om2,om3
Fiber Count: 2-24 Core
Outer Sheath Material: PE,HDPE,MDPE,LSZH
Applications: Reconstruction of old power lines and low voltage level lines. Coastal chemical industrial areas with heavy chemical pollution
Applicable Voltage Range: Power lines with voltage level of 220KV and below


  • Wide Attenuation Range

  • Low Return Loss

  • Low PDL

  • Polarization Insensitive

  • Various connector type

  • Highly Reliable

  • Complies with industry green initiative such as ROHS



  • FTTX Systems

  • LAN, WAN and Metro Networks

  • Analog/Digital Passive Optical Networks

  • CATV Networks

  • Other applications in fiber optic systems



Specifications

Specifications
Wavelength (nm) SMF:1310/1550 ; MMF:850/1300
Repetitiveness (dB) ≤0.1
Attenuation range (dB) 0-15
Attenuation tolerance (dB) 0-5:±0.5     5-15:±10%
Interchangeability (dB) ≤0.2
Plug times 1000times ≤0.2
MAX Optical Power(mw) ≤200
Operating Temperature(℃) -40~+85


Packing


Packing
Simplex 2000pcs/carton
Weight 8.5kg
Carton Dimension 470x310x210mm
