FTT-H208C 8 Port FTTH Terminal Box white


Capacity: 8 port
Connector type: SC simplex, LC duplex
Applications: FTTx wall mount and pole mount


  1. Mechanical seal: good sealing, can repeat use.

  2. Protective level IP65

  3. Laying for outdoor wall-mounting and pole-mounting

  4. FTTH products , passive optical points wiring special terminal box

  5. The box body to scroll type structure, it has the function of guard against theft, large capacity function complete, easy to use

  6. Can meet the following  Ф16 cable into, and can meet the figure 8 or Ф3 cable protective in splice connection

  7. Can be installed 1:8 SC or 1:16 LC Mini-splitter / cassette PLC splitter



Model NoFTT-H208C
Dimension( L×W×H )252X210X72mm
Functioncable terminal, passive splitter
Adaptor typeSC /LC
Material PC
ColorWhite, black
Capacity

2 inlet port, 16mm cable diameter

8 outlet port, 3.0mm indoor cable or 2.0x3.0mm drop fiber optic cable

Max PLC splitter ratio1:8, 1:4
Max splicecapacity(F)LC biggest for 16 core, SC biggest for 8 core
IP protectionIP65


FTT-H208C
Packing 20pcs/carton box
Dimension( L×W×H ) 52.5x45x42.5cm
Weight 23KG

   carton box
