Excellent tensile strength for such small diameter.
Low dispersion and attenuation
Proper design, precise control for fiber excess length render the cable excellent mechanical and environmental properties.
Small cable diameter, light cable weight, easily to install.
a steel wire messenger
Excellent tensile strength for such small diameter.
Low dispersion and attenuation
Proper design, precise control for fiber excess length render the cable excellent mechanical and environmental properties.
Small cable diameter, light cable weight, easily to install.
a steel wire messenger
No. of cable | 2-12 | ||
Fiber Model | G.652D | ||
Loose Tube | Material | PBT | |
Diameter(±0.06)mm | 1.6 | ||
Thickness(±0.03)mm | 0.32 | ||
The Max.Core NO./Tube | 12 | ||
Outer Sheath | Material | MDPE | |
Thickness(±0.2)mm | 1.0 | ||
Web | Material | MDPE | |
Size(±0.2)mm | 0.5*1.5 | ||
Messenger Wire | Material | Steel wire | |
Diameter(±0.05)mm | 1.0 | ||
Cable Diameter(±0.3)mm(W×H) | 3.8*6.8 | ||
Cable Weight(±3)kg/km | 22 | ||
Min. bending radius | Without Tension | 10×Cable-φ | |
Under Maximum Tension | 20×Cable-φ | ||
Temperature range (℃) | Installation | -20~+60 | |
Transport&Storage | -40~+70 | ||
Operation | -40~+70 |
No. of cable | 2-12 | ||
Fiber Model | G.652D | ||
Loose Tube | Material | PBT | |
Diameter(±0.06)mm | 1.6 | ||
Thickness(±0.03)mm | 0.32 | ||
The Max.Core NO./Tube | 12 | ||
Outer Sheath | Material | MDPE | |
Thickness(±0.2)mm | 1.0 | ||
Web | Material | MDPE | |
Size(±0.2)mm | 0.5*1.5 | ||
Messenger Wire | Material | Steel wire | |
Diameter(±0.05)mm | 1.0 | ||
Cable Diameter(±0.3)mm(W×H) | 3.8*6.8 | ||
Cable Weight(±3)kg/km | 22 | ||
Min. bending radius | Without Tension | 10×Cable-φ | |
Under Maximum Tension | 20×Cable-φ | ||
Temperature range (℃) | Installation | -20~+60 | |
Transport&Storage | -40~+70 | ||
Operation | -40~+70 |
Fiber | Length/KM | packing size/cm |
2-30 | 2 | 100×100×70 |
3 | 110×110×70 | |
4 | 125×125×90 | |
32-60 | 2 | 100×100×70 |
3 | 110×110×70 | |
4 | 125×125×90 | |
60-72 | 2 | 100×100×70 |
3 | 110×110×70 | |
4 | 125×125×90 | |
Packing | Wooden drum |
Fiber | Length/KM | packing size/cm |
2-30 | 2 | 100×100×70 |
3 | 110×110×70 | |
4 | 125×125×90 | |
32-60 | 2 | 100×100×70 |
3 | 110×110×70 | |
4 | 125×125×90 | |
60-72 | 2 | 100×100×70 |
3 | 110×110×70 | |
4 | 125×125×90 | |
Packing | Wooden drum |
