Outdoor Fiber Optic Cable GYFTY 48F


Fiber Type: Singlemode / Multimode / OM1 / OM2 / OM3
Fiber Count: 48F
Span Length: 100M
Applications
Underground/duct and buried

  1. Good mechanical and temperatureperformance

  2. High strength loose tube that is hydrolysisresistant

  3. Special tube filling compound ensure a critical protection offiber

  4. Crush resistance andflexibility

  5. The following measures are taken to ensure the cablewatertight

  6. Single Fiber Reinforced Plastic as the central strengthmember

  7. 100% Loose tube fillingcompound

  8. 100% cable corefilling


No. of cable
4
8
12
24
48
72
Fiber Model
G.652D
Design(Strength Member + Tube &Filler)
1+5
1+6
Central Strength
Member
Material
FRP
Diameter(±0.05)mm
1.5
2.0
Loose Tube
Material
PBT

Diameter(±0.06)mm
1.72
2.0
Thickness(±0.03)mm
0.30
0.32
The Max. Core NO./Tube
4
6
12

Filler Rope
Material
LDPE
Color
White
Diameter(±0.06)mm
1.7
2.0
Water Blocking layer(Material)
Flooding Compound
Outer
Sheath
Material
MDPE
Thickness(±0.2)mm
1.8
Cable Diameter
8.3
8.9
9.4
13.2
Cable Weight
55
65
75
160

Min. bending radius
Without Tension
10.0×Cable -φ
Under Maximum Tension
20.0×Cable -φ
Temperature range(℃)
Installation
-20~+60
Transport & Storage
-40~+70
Operation
-40~+70



Fiber

Length/KM

packing size/cm

2-30 2 100×100×70
3 110×110×70
4 125×125×90
32-60 2 100×100×70
3 110×110×70
4 125×125×90
60-72 2 100×100×70
3 110×110×70
4 125×125×90
Packing Wooden drum
